YuSynth Audio/CV Input Mixer 2U Module Bare Electronics Parts Kit


£7.43
(£6.19 exc. tax)
7220-243
40.00 g.
In stock
Made to order
Normally dispatched within 1-4 days
+
Add to wish list

Have the right skills, tools and test gear to build your own modular synth, then our kits of parts may be just what you need. As a minimum, you will need to be able to identify electronic components, recognise when they need to be correctly orientated, to be able to use a small soldering iron and finally have access to test equipment. Some modules do not require the use of test equipment but any requirement will be in the 'Setting and Trimming' notes.

The kits include all required electronics components as well as pots & switches. The PCB, connectors and knobs are not included but available from Soundtronics as an option. Our, front panel + matching back panel* really finish off the module in a truly professional way. If you purchase the PCB and components through Soundtronics, then we will also support you with technical assistance just in case you get into any build difficulties.

We only source quality components and we even include the more expensive turned pin IC sockets as we feel the product justifies the extra cost both for reliability and serviceability. Our optional 1/4" jack sockets are by Switchcraft, yes you can save money by buying cheaper sockets hence us offering it as an option because we recognise they are a significant cost. We have standardised on Cliff KM20 knobs for all of our modules but again, as it's an option you can choose different knobs to suit your own preference. Finally, all components are available individually should you not need to purchase the whole kit.

*Coming soon

Components Kit Contents (excludes PCB, sockets and knobs) Also available in a 1U version

Reference Part No. Description Qty
R1, R2 7163-007 10R 0.25W 1% Metal Film Resistor 2
R13 7163-043 470R 0.25W 1% Metal Film Resistor 1
R8, R11 7163-051 1k 0.25W 1% Metal Film Resistor 2
R16 7163-061 2k7 0.25W 1% Metal Film Resistor 1
R17 7163-063 3k3 0.25W 1% Metal Film Resistor 1
R15 7163-071 6k8 0.25W 1% Metal Film Resistor 1
R12, R18 7163-077 12k 0.25W 1% Metal Film Resistor 2
R3, R4, R5, R6, R7, R9, R10, R14 7163-101 120k 0.25W 1% Metal Film Resistor 8
U1 7212-331 Turned Pin 0.3 inch Dil IC Socket 8 Pin 1
Q1 7212-401 BC547C Diotec Bipolar NPN Transistor TO-92 1
D1,  D2,  D3,  D4 7212-480 1N4148 Signal Diode 4
U1 7212-542 Dual Op-Amp BiFET TL072CP 1
C3, C4, C5 7212-749 100nF 5mm X7R Dielectric Radial Ceramic Capacitor 3
C1, C2 7213-106 Radial Electrolytic Capacitor 10uF 25V 2
LD1 7213-900 5mm Single Piece LED Panel Mounting Clip - Prominent 1
LD1 7213-902 5mm LED Green High Efficency 20mcd 1
P1, P2, P3, P4, P5 7300-250 Synth Pot 16mm 50k Lin 5
P6 7300-255 Synth Pot 16mm 100k Lin 1
