MFOS Sound Lab Ultimate Expander Bare PCB

£51.12
(£61.34 UK, incl VAT)
7210-075
85 g
In stock
+

A bare PCB in the new black solder resist colour for the MFOS Sound Lab Expander project.

The MFOS Sound Lab ULTIMATE EXPANDER in combination with an MFOS Sound Lab ULTIMATE is a completely full featured modular synthesizer. Although specifically designed to be a companion to the Sound Lab ULTIMATE the ULTIMATE EXPANDER has the features to stand on its own as a super "Swiss Army Knife" module. The MFOS Sound Lab ULTIMATE EXPANDER includes:



  • A State Variable Voltage Controlled Filter (doubles as a 1V/oct sine wave oscillator over several octaves)
  • A Voltage Controlled Amplifier (expo response)
  • An ADSR Envelope Generator
  • A Four Channel Active Mixer
  • A One-In Three-Out Voltage Distributor
  • A CV Inverter
  • An Analog Multiplier (Ring Modulator)
  • An External Signal Buffer
  • An Envelope Follower
  • Two Passive Voltage Attenuators
  • A Headphone Amplifier
  • Signal Routing and Buffering for The Sound Lab ULTIMATE
  • Patch Panel Design

Check out our components section for any components you need to complete the project. If you can't find what you need then contact us as we are sure to have it in stock and simply missed listing it.

Hi, probably a question asked elsewhere i apologize.... Is MFOS cv voltage broadly compatible with Eurorack? Eg 0to10V, -5Vto+5V, that kind of thing? Thanks, Nick

Asked by Nick Walker | 11/09/2021, 21:51 | 1 answer(s)

Hi, We looking for Main Face Plate (Part# ULTEXPANDERFPMAIN) and Aux Face Plate (Part# ULTEXPANDERFPAUX) for this project. Please help me. Regards, Dariusz, Poland

Asked by Dariusz Filipowski | 03/02/2016, 11:06 | 1 answer(s)
