MFOS Multi Function Synth Module DIY Electronics Parts Kit

List price: £30.71
£22.24
(£26.69 UK, incl VAT) You save: £8.47 (28%)
7210-240
200 g
2 item(s)
End of line
+
Add to wish list

Have the right skills, tools and test gear to build your own modular synth, then our kits of parts may be just what you need. As a minimum, you will need to be able to identify electronic components, recognise when they need to be correctly orientated, to be able to use a small soldering iron and finally have access to test equipment. Some modules do not require the use of test equipment but any requirement will be in the 'Setting and Trimming' notes.

The kits include all required electronics components as well as pots & switches. The PCB, connectors and knobs are not included but available from Soundtronics as an option. Our front panel + matching back panel really finish off the module in a truly professional way. If you purchase the PCB and components through Soundtronics, then we will also support you with technical assistance just in case you get into any build difficulties.

We only source quality components and we even include the more expensive turned pin IC sockets as we feel the product justifies the extra cost both for reliability and serviceability. Our optional 1/4" jack sockets are by Switchcraft, yes you can save money by buying cheaper sockets hence us offering it as an option because we recognise they are a significant cost. We have standardised on Cliff KM20 knobs for all of our modules but again, as it's an option you can choose different knobs to suit your own preference. Finally, all components are available individually should you not need to purchase the whole kit.

Each Kit Contains:

Qty Reqd. Description Value Designators St Part No.
1 Zener Diode 500mW 9.1V, Fairchild,  1N5239B 9V1 Z1   2101-503
6 100R 0.25W 1% Metal Film Resistor 100R R35, R42, R48, R55, R69, R81   7163-027
1 200R 0.25W 1% Metal Film Resistor 200R R76   7163-034
2 2k 0.25W 1% Metal Film Resistor 2k R14, R33   7163-058
1 3k 0.25W 1% Metal Film Resistor 3k R2   7163-062
1 4k7 0.25W 1% Metal Film Resistor 4k7 R75   7163-067
20 10k 0.25W 1% Metal Film Resistor 10k R1, R12, R15, R18, R20, R24, R26, R27, R29, R31, R32, R39, R40, R53, R54, R66, R67, R71, R77, R78   7163-075
1 20k 0.25W 1% Metal Film Resistor 20k R68   7163-082
1 30k 0.25W 1% Metal Film Resistor 30k R9   7163-086
3 68k 0.25W 1% Metal Film Resistor 68k R3, R10, R74   7163-095
1 91k 0.25W 1% Metal Film Resistor 91k R17   7163-098
9 100k 0.25W 1% Metal Film Resistor 100k R4, R5, R8, R37, R41, R51, R52, R70, R80   7163-099
2 200k 0.25W 1% Metal Film Resistor 200k R11, R23   7163-106
1 270k 0.25W 1% Metal Film Resistor 270k R7   7163-109
4 300k 0.25W 1% Metal Film Resistor 300k R36, R38, R46, R47   7163-110
16 1M 0.25W 1% Metal Film Resistor 1M R13, R16, R19, R21, R22, R25, R28, R30, R43, R49, R50, R57, R58, R60, R62, R64   7163-122
1 10M 0.25W 1% Metal Film Resistor 10M R73   7163-125
2 SPDT Miniature Toggle Switch   S2, S3   7212-250
1 DPDT on/off/on Miniature Toggle Switch   S1   7212-255
1 Turned Pin 0.3 inch Dil IC Socket 8 Pin     7212-331
7 Turned Pin 0.3 inch Dil IC Socket 14 Pin     7212-332
8 2N3906 40V TO92 PNP AUDIO Transistor   Q1, Q2, Q3, Q4, Q5, Q6, Q7, Q8   7212-410
2 1N914 75V Signal Diode   D1, D2   7212-486
1 Dual Op-Amp BiFET TL072CP   U8   7212-542
7 Quad Op-Amp BiFET TL074   U1, U2, U3, U4, U5, U6, U7   7212-544
1 47pF 2.5mm COG NPO Monolithic Radial Ceramic Capacitor 47pF C20   7212-733
3 100pF 2.5mm COG NPO Monolithic Radial Ceramic Capacitor 100pF   C1, C15, C16   7212-734
13 100nF 5mm X7R Dielectric Radial Ceramic Capacitor 100nF C2, C3, C4, C5, C6, C7, C8, C11, C12, C13, C14, C18, C19   7212-749
1 220nF 5mm Y5V Dielectric Radial Ceramic Capacitor 220nF C21   7212-750
1 1uF 5mm Y5V Dielectric Radial Ceramic Capacitor 1uF C17   7212-751
1 Multiturn Cermet Preset Top Adjust SIL 20k 20k R6   7212-858
2 Radial Electrolytic Capacitor 10uF 25V 10uF 25V   C9, C10   7213-106
1 2.2uF 50V Non-Polarised Electrolytic Capacitor 2u2 C22   7213-305
11 5mm Single Piece LED Panel Mounting Clip - Prominent   LED1  to LED11 7213-900
10 5mm LED Red High Efficency 45mcd Red LED1, LED3, LED5, LED8, LED2, LED4, LED7, LED9, LED11, LED10   7213-901
1 5mm LED Green High Efficency 20mcd Green LED6   7213-902
6 Synth Pot 16mm 10k Lin 10k R44, R56, R59, R61, R63, R65   7300-230
2 Synth Pot 16mm 100k Lin 100k R34, R45   7300-255
2 Synth Pot 16mm 1M Lin 1M R72, R79   7300-270
