MFOS Dual AR Synth Module DIY Electronics Parts Kit

List price: £24.62
£20.30
(£24.36 UK, incl VAT) You save: £4.32 (18%)
7210-221
113 g
3 item(s)
End of line
+
Add to wish list

Have the right skills, tools and test gear to build your own modular synth, then our kits of parts may be just what you need. As a minimum, you will need to be able to identify electronic components, recognise when they need to be correctly orientated, to be able to use a small soldering iron and finally have access to test equipment. Some modules do not require the use of test equipment but any requirement will be in the 'Setting and Trimming' notes.

The kits include all required electronics components as well as pots & switches. The PCB, connectors and knobs are not included but available from Soundtronics as an option. Our front panel + matching back panel really finish off the module in a truly professional way. If you purchase the PCB and components through Soundtronics, then we will also support you with technical assistance just in case you get into any build difficulties.

We only source quality components and we even include the more expensive turned pin IC sockets as we feel the product justifies the extra cost both for reliability and serviceability. Our optional 1/4" jack sockets are by Switchcraft, yes you can save money by buying cheaper sockets hence us offering it as an option because we recognise they are a significant cost. We have standardised on Cliff KM20 knobs for all of our modules but again, as it's an option you can choose different knobs to suit your own preference. Finally, all components are available individually should you not need to purchase the whole kit.

Each Kit Contains:



Qty Reqd. Description Value Designators ST part No.
6 1k 0.25W 1% Metal Film Resistor 1k R4, R6, R9, R29, R32, R35   7163-051
5 3k 0.25W 1% Metal Film Resistor 3k R23, R10, R11, R36, R37   7163-062
2 4k7 0.25W 1% Metal Film Resistor 4k7 R13, R39   7163-067
1 9k1 0.25W 1% Metal Film Resistor 9k1 R26   7163-074
2 10k 0.25W 1% Metal Film Resistor 10k R5, R30   7163-075
2 20k 0.25W 1% Metal Film Resistor 20k R25, R1   7163-082
1 33k 0.25W 1% Metal Film Resistor 33k R27   7163-087
9 47k 0.25W 1% Metal Film Resistor 47k R12, R22, R15, R17, R18, R38, R41, R44, R43   7163-091
12 100k 0.25W 1% Metal Film Resistor 100k R28, R21, R14, R19, R24, R2, R20, R48, R47, R45, R46, R40   7163-099
2 10M 0.25W 1% Metal Film Resistor 10M R16, R42   7163-125
2 SPDT Miniature Toggle Switch   S4, S8   7212-250
2 DPDT Miniature Toggle Switch   S3, S7   7212-252
2 Low Profile Push to Make Switch, Black   S2, S6   7212-254
2 SPDT on/off/on Miniature Toggle Switch   S1, S5   7212-251
1 Turned Pin 0.3 inch Dil IC Socket 8 Pin     7212-331
4 Turned Pin 0.3 inch Dil IC Socket 14 Pin     7212-332
4 2N3904 Transistor NPN TO-92 60V   Q1, Q2, Q3, Q4   7212-409
8 1N914 75V Signal Diode   D4, D3, D2, D1, D8, D7, D6, D5   7212-486
1 4013B Dual D Type Flip Flop   U3   7212-509
1 4066B Quad Bilateral Switches   U2   7212-514
1 Dual Op-Amp BiFET TL072CP   U4   7212-542
2 Quad Op-Amp BiFET TL074   U1, U5   7212-544
2 10pF 2.5mm COG NPO Monolithic Radial Ceramic Capacitor 10pF   C8, C27   7212-730
2 1nF 5mm X7R Dielectric Radial Ceramic Capacitor 1nF C15, C29   7212-740
4 10nF 5mm X7R Dielectric Radial Ceramic Capacitor 10nF C7, C6, C25, C26   7212-746
14 100nF 5mm X7R Dielectric Radial Ceramic Capacitor 100nF C16, C17, C18, C2, C19, C20, C13, C12, C9, C10, C5, C30, C28, C24   7212-749
2 220nF 5mm Y5V Dielectric Radial Ceramic Capacitor 220nF C1, C21   7212-750
2 Radial Electrolytic Capacitor 10uF 25V 10uF 25V   C14, C11   7213-106
2 Tantalum Bead Capacitor 25V 1uF 1uF 25V  2.5mm C3, C22   7213-205
2 Tantalum Bead Capacitor 35V 4.7uF 4u7 35V 2.5mm C4, C23   7213-211
4 Synth Pot 16mm 1M Log 1M   R7, R8, R33, R34   7300-070
2 Synth Pot 16mm 10k Lin 10k R3, R31   7300-230
