AS3310 ADSR Generator Chip

AS3310 ADSR Envelope Generator 16-Pin DIP


£4.62 incl VAT
(£3.85 exc. tax)
Price in points: 770 points
7212-588
1.00 g.
In stock
+
Add to wish list

Check out our ADSR project using the AS3310 here.

The CEM range of synth chips featured in numerous commercial and DIY synths in the 80’s before they ceased production. A number of the chips have been remanufactured by a Latvian electronics company and we delighted to be able to offer them through Soundtronics. Going forward, we will be designing synth modules using these chips.

The AS3310 is a self-contained, precision ADSR type of envelope generator intended for electronic music and other sound generation applications. Attack, decay and release times are exponentially voltage controllable over a wide range, and the sustain level is linearly voltage controllable from 0 to 100% of the peak voltage Vp. All four control Inputs are Isolated from the rest of the circuitry so that the control pins of tracking units may be simply tied together.

Features

  • Large Time Control Range: 100,000:1
  • Full ADSR Response
  • True RC Envelope Shape
  • Exceptionally Low Control Voltage Feed through: 90μVmax
  • Accurate Exponential Time Control Scales
  • Isolated Control Inputs
  • Good Repeatability and Tracking Between Units Without External Trim
  • Independent Gate and Trigger
  • Wide power supply range:

negative rail: -15V to -9V (via external resistor), positive rail: +11V to +15V

No FAQ found

No posts found

Write a review

AS3310 Datasheet (7212-588-AS3310.pdf, 437 Kb) [Download]
